Solar CFL Street Light Luminaries

Technical Specification
CFL based Street Light System
Technical details CFL-11 Watt CFL-18 Watt CFL-22 Watt
SPV Module 1x75Wp 1x100Wp 2x75Wp
Battery@C10 12V 75Ah 12V 100Ah 12V 150Ah
Lamp/Wattage 1x11 W 1x18 W 2x11 W
Lamp Luminosity 1x900 Lumens 1200 Lumens 2x900 Lumens
Daily Usage Capacity Dusk to dawn Dusk to dawn Dusk to dawn
Storage Autonomy 4 Days 4 Days 4 Days
PWM Charge Contoller 6 Amps 10 Amps 10 Amps
Pole, Battery Box and Mounting Structure 4.5 Mtr Galvanised/ MS with Powder Coated 4.5 Mtr Galvanised/ MS with Powder Coated 4.5 Mtr Galvanised/ MS with Powder Coated

Features

Applications
