Technical Specification

VA Rating	:	200 va to 1 kva
Mains input coputer mode	:	90v to 300v adjustable
Normal mode	:	180v to 280v adjuatable
Input dc	:	12v
Input frequency range	:	40 to 60 HZ
Output frequency	:	49 to 51 HZ
Output voltage in inverter	:	220v to 250v
Inverter efficiency	:	80%
Typical transfer time	:	10 ms
Power factor	:	0.8



Features

• Micro chip based technology
• Computer compatibility option
• 200 va to 1 kva
• Triac based normal / boost charger
• Mains high voltage & low voltage cut off
• Option for external/built in by pass relay
• Jumper/precet for battery full cut off,charging current full width inverter charging restart voltage etc
• 180v to 270 v regulated output in inverter & mains for any load
• Over current of mosfets protected with in micro seconds
• Can accept any input waves if voltage & freqrency is with in limit
• Near RMS measurementsfor all calculations
• Short circuit protection
• Over load restart up to 5 times
• Automatic battery health check up as well as battery bad detection
• Zero current drains from battery after any trip conditions
• Watchdog timer implement is to prevent CPU hangs up
